Specs for Atlantic Blowers Two Stage Regenerative Blower 1.5 inch 113 CFM 1 Phase AB-302/1
Item #: AB-302-1
19 / 10
113
USA
841459
60 / 50
3
1.5"
Yes
1.5"
1 Phase
15" x 15" x 15"
73 lbs
113
2 Stage
120 / 240
1 Year Limited
Texas, USA
Atlantic Blowers Two Stage Regenerative Blower 1.5 inch 113 CFM 1 Phase AB-302/1
Atlantic Blowers' AB-302/1 Single Phase/Double Stage Regenerative Blower can be used for various pressure or vacuum applications. The AB-302/1 produces a maximum flow of 113 CFM.
The maximum pressure and vacuum is 118 in H2O and 110 in H2O respectively. The AB-302/1 has a power output of 1.5 HP (1.1 kW) with speeds of either 3000 or 3600 RPM (50/60 Hz dual frequency).
The voltage is 110-120V/220-240V with an FLA rating of 19.0/10.0. Measuring at a distance of 3 ft. the blower will produce a noise level of 68 dbA. The inlet/outlet connection size is 1.50" female NPT.
