Specs for Atlantic Blowers Two Stage Regenerative Blower 1.25 inch 58 CFM 1 Phase AB-102/1
Item #: AB-102-1
7.8 / 3.9
1.25"
58
USA
841459
60 / 50
1
1.25"
Yes
1.25"
1 Phase
15" x 15" x 15"
47 lbs
64
2 Stage
120 / 240
1 Year Limited
Texas, USA
Atlantic Blowers Two Stage Regenerative Blower 1.25 inch 58 CFM 1 Phase AB-102/1
NOTE: CORD AND PLUG NOT INCLUDED.
The Atlantic Blowers AB-102/1 Single Phase/Double Stage Regenerative Blower can be used for various pressure or vacuum applications. The AB-102/1 produces a maximum flow of 58 CFM.
The maximum pressure and vacuum is 59 in H2O and 40 in H2O respectively. The AB-102/1 has a power output of 0.5 HP (0.4 kW) with speeds of either 3000 or 3600 RPM (50/60 Hz dual frequency).
The voltage is 110-120V/220-240V with an FLA rating of 7.8/3.9. Measuring at a distance of 3 ft. the blower will produce a noise level of 68 dbA. The inlet/outlet connection size is 1.25" female NPT.
