Specs for Coppus 16 inch Air-Driven Reaction Fan 5100 CFM at 80 PSIG Inlet Pressure RF-16
Item #: 150030300-RF-16
144
16"
Cast Aluminum
5100
USA
Pneumatic
841459
80
Yes
17" x 18" x 12"
50 lbs
5100
One Year Limited
Florida, USA
Coppus 16 inch Air-Driven Reaction Fan 5100 CFM at 80 PSIG Inlet Pressure RF-16
Rugged, cast aluminum housing and fan blade make these fans ideal for hazardous locations and demanding ventilation projects. The RF design uses action-reaction principles - compressed air is discharged through nozzles located at the tip of the fan blade providing extremely efficient, high-volume, low-maintenance air movers.
FEATURES Use for fresh air supply or fume exhaust Low compressed air consumption Spark-resistant, cast-aluminum housing and fan blade Virtually maintenance free Permanently lubricated bearings eliminate line oiler Cast-in handles and feet Cast-in bead to accept 16 inch duct Bolt holes allow optional adapter plates attachment
